Module quang 10G 40Km
Module quang 10G 40Km
★ Sản phẩm chính hãng ®- Thông số sản phẩm:
- Chuẩn kết nối: LC
- Hãng sản xuất: Cablexa
- Mã sản phẩm: SFP-10G-SM15-40KM
- Loại sản phẩm: Module quang 10G
- Dòng sản phẩm: Module quang SFP
- Tình trạng: Mới 100%
- Bảo hành: Chính hãng
- Trạng thái: Còn hàng
- Giao hàng: Toàn quốc
Module quang 10G 40Km 2 sợi Cablexa SFP-10G-SM15-40KM
Module Cablexa SFP-10G-SM15-40KM Cablexa 10G SFP+ Dual Fiber Single Mode 1550nm 40km LC DDM chính hãng phân phối bởi Siêu Thị Mạng
Module quang 10G 40Km, báo giá phân phối Module quang 10G 40Km SMF loại 2 sợi quang, tốc độ 10G chính hãng có đầy đủ giấy tờ, bảo hành 24 tháng, cam kết uy tín, giá rẻ.
Đặc trưng của Module SFP-10G-SM15-40KM hãng Cablexa
- Tốc độ dữ liệu hoạt động lên đến 10,3Gbps
- Máy phát DFB-LD 1550nm
- Khoảng cách lên đến 40km
- Nguồn cấp 3. 3V đơn và Giao diện logic TTL
- Giao diện đầu nối LC song công, có thể cắm nóng
- Tuân thủ MSA SFP + đặc điểm kỹ thuật SFF-8431
- Tuân theo tiêu chuẩn 10G FC 1200-SM-LL-L FC
- Tuân theo tiêu chuẩn 8.5G FC-PI-4 800-SM-LC-L FC
- Tuân theo tiêu chuẩn 4,25G FC-PI-4 400-SM-LC-L FC
- Tuân theo tiêu chuẩn 2.125G FC-PI-4 200-SM-LC-L FC
- Tuân theo tiêu chuẩn 1.0625G FC-PI-4 100-SM-LC-L FC
- Tuân theo IEEE 802.3ae 10GBASE-LR / LW
Thông số kỹ thuật Module SFP-10G-SM15-40KM hãng Cablexa
Hãng | Cablexa |
Mã sản phẩm | SFP-10G-SM15-40KM |
Loại sản phẩm | Mô-đun thu phát |
Yếu tố hình thức | SFP + |
Tốc độ dữ liệu (tối đa) | 10,5 Gb / s |
Khoảng cách (tối đa) | 40KM |
Máy phát | 1550nm DFB |
Người nhận | PIN |
Chẩn đoán kỹ thuật số | Có |
Đầu nối | LC Duplex |
Loại cáp | SMF |
Bước sóng | 1550nm |
Nhiệt độ hoạt động | COM / EXT / IND |
Features
- Operating data rate up to 10.3Gbps
- 1550nm DFB Transmitter
- Distance up to 40km over SMF
- Single 3.3V Power supply and TTL Logic Interface
- Duplex LC Connector Interface,Hot Pluggable
- Compliant with SFP+ MSA Specification SFF-8431
- Compliant with IEEE 802.3ae 10GBASE-ER
- Compliant with IEEE 802.3ae 10GBASE-EW
- Compliant with SFF-8472
- Operating Case Temperature Standard:0℃~+70℃
Applications
- 10GBASE-ER at 10.31Gbps
- 10GBASE-EW at 9.95Gbps
- 1000 Base-LX Ethernet
- 8x FC at 8.5Gbps
- 4x FC at 4.25Gpbs
- 2x FC at 2.125Gpbs
- 1x FC at 1.0625Gbps
Specifications
- Part Number: SFP-10G-SM15-40KM
- Product Type: Transceiver Module
- Form Factor: SFP+
- Data Rate (max): 10.5 Gb/s
- Distance (max): 40KM
- Transmitter: EML
- Receiver: PIN
- Digital Diagnostic: Yes
- Connector: Duplex LC
- Cable Type: SMF
- Wavelength: 1550nm
- Operating Temperature: 0 to 70°C (32 to 158°F)
Labelling
- Cablexa Logo (Default)
- Generic Label
- Custom Label
This SFP-10G-SM15-40KM is marked and labelled with Cablexa brand as default. Customized labelling and branding are available as request.
Warranty
Cablexa offers 5-year limited warranty on this SFP-10G-SM15-40KM optical transceiver module.
Quality Guarantee
Cablexa offers a large selection of optical transceivers that are compatible with all the major brands. We also carry transceivers in various form factors to meet your networking needs. Now you have a reliable, compatible and affordable means to expand your network while maintaining its integrity. All of Cablexa's transceivers are tested for 100% functionality and guaranteed compatible for outstanding network performance.
This Cablexa SFP+, 10Gb/s, 10GBase-ER, SMF, 1550nm, Duplex LC, 40KM Transceiver Module is 100% MSA compliant. It is guaranteed compatible with your router or switch. And it comes with a 5-year warranty and lifetime technical support. If you have any questions about this SFP-10G-SM15-40KM transceiver module or any other item, feel free to contact us.
